BTI builds balancing and spin test equipment for power generation — generator and exciter rotors, turbine rotors and discs, and the large induced- and forced-draft fans that move air through a plant. These are among the heaviest rotors BTI handles, and the ones where an unplanned outage costs the most.

What BTI Balances in Power Generation

BTI balancing machines are built on four platforms — VNR (vertical non-rotator), H (horizontal cradle), VR (vertical rotator) and P (platform suspension) — plus tool holder balancers, spinners and test stands. The platform follows the part geometry and how it has to be held; the correction method follows the material and where there is room to add or remove mass.

Component	Typical platform	Correction method
Generator and exciter rotors	H	Drill, weight-add
Turbine rotors and discs	H	Mill, grind, weight-add
Induced and forced draft fans	P, H	Weld-on weight
Coupling and shaft assemblies	H	Drill
Turbine-driven pump rotors	H, VR	Mill, weight-add

How a Machine Gets Sized

A BTI machine designation names a platform and a class. A P-5 is the platform suspension base, class 5. The number is a class, not a part weight limit — it describes the size and load envelope of the base. Sizing works from the tooling and the part together, not the part alone. Tooling is not specified until the part prints are reviewed and the fixture is concepted, and the heavier the tooling-plus-part assembly is relative to the class, the less repeatable the measurement becomes. A shop that needs one machine to cover a wide range of parts, and does not need tight repeatability, can run a much broader weight range on a given class than a production program can. Tell BTI the part weight and BTI will name a class the same day. See BTI machine platforms for the full platform and class architecture.

Balance Grade and Tolerance

Balance tolerances are set by ISO 21940-11, which superseded ISO 1940-1. The standard assigns a balance quality grade G, and the permissible residual specific unbalance follows from that grade and the service speed: e_per = (G × 60) ÷ (2π × n) where e_per is permissible residual specific unbalance in g·mm/kg, G is the balance quality grade in mm/s, and n is the service speed in rev/min. Permissible residual unbalance is then U = e_per × m, divided across the correction planes.

Grade	Typical components
G 2.5	Gas and steam turbines, rigid turbo-generator rotors, turbo-compressors, turbine-driven pumps
G 6.3	Fans, process plant machines, centrifuge drums

Work out a specific tolerance with the ISO balance tolerance calculator.

Low-Speed Balancing and the Flexible Rotor Problem

Most production balancing is low-speed: the rotor is treated as rigid, measured well below service speed, and corrected in two planes. A long, slender rotor running near or above a critical speed does not behave that way — it bends, and its unbalance distribution changes with speed. Those rotors need multi-plane correction and, in some cases, balancing at or near service speed on a spin stand rather than a conventional balancer. Which regime a rotor falls into is a function of its geometry and its service speed, and it is one of the first things BTI establishes from the part print.

Correction Methods

Method	Where it fits
Drill	Cast and forged parts with material available to remove
Mill	Controlled removal on a defined correction band
Grind	Hardened or finished surfaces
Weld-on weight	Shafts and assemblies, adding rather than removing mass
Clip-on or press-on weight	Wheels, fan wheels and rims
Adhesive and applied weight	Modules, plastics and assemblies

Standards

BTI certifies machines to ISO 21940, SAE International balancing specifications, and DIN specifications. Where a program carries a measurement system capability requirement, BTI evaluates the part and the process first, then confirms what is achievable and commits to it in the machine specification.

Frequently Asked Questions

What is the difference between low-speed and high-speed balancing?

Low-speed balancing treats the rotor as rigid and corrects in two planes at a convenient measuring speed. High-speed balancing runs the rotor at or near service speed to capture bending behaviour, and is used where the rotor operates near a critical speed.

Does BTI build spin test equipment as well as balancers?

Yes. BTI builds spin test stands and spinners, and also offers spin testing as a service.

Does BTI rebuild or retrofit existing balancing machines?

Yes, including machines built by other manufacturers. See BTI rebuilds and retrofits, competitor rebuilds and retrofits, and PC upgrades.

How are BTI lead times quoted?

Lead times are quoted in weeks at the time of quotation. They move with current backlog, so BTI confirms the schedule for a specific machine as part of the quote rather than publishing a fixed figure.
